5G Integrated gNB

The nCELL-M4370 from BTI WIRELESS is based on advanced multi-core ARM and FPGA solutions and adopts an integrated design method of 5G BBU and RRU. Based on a completely independent research and development protocol stack and system software, it realizes a complete 5G NR wireless access, which can quickly provide users with a reliable 5G wireless coverage network. The nCELL-M4370 has the advantages of low power consumption, small size, convenient construction, etc., and is suitable for applications in many 5G vertical industries.

Applications:
5G

Outdoor Scenario

Urban

Private Network

Easy installation

Compact and light base station, plug and play.

Customization

Support customization to meet your various needs.

Reliable

Fast, secure wireless network and remote device management.

Secure

Conducting regular safety tests to ensure the security of the data transmitting.

- N38/N40/N41/N48/N77/N78
- Support customization

Key Features and Highlights

- Integrated design of baseband and radio head
- Based on 3GPP R16 technology with high-speed data and low latency services
- Supports external antenna or integrated antenna
- Supports 400 RRC Subs
- Supports GPS, 1588V2 clock synchronization
- Web-based management, convenient and intuitive
- Humanized indicator light, easy to observe and manage equipment status

Specification

Item	5G Integrated gNB nCELL-M4370
Output Power	4x5W
MIMO	1 x 4T4R or 2 x 2T2R
Working Bandwidth	10/20/40/50/60/80/100 MHz
User Capacity	400 RRC Subs
Ingress Protection	IP67
Size	378.5 x 278.5 x 195 mm \| 14.90 x 10.96 x 7.68 in
Weight	< 17 kg \| 37.48 lbs
